Sliding door hardware Runway, wood, front-mounted

The Runway barn door hardware for wooden doors, front-mounted, features a modern and clean design with concealed rollers that make the carriage appear to glide invisibly along the track. Unlike ceiling-mounted systems, the front-mounted version allows direct installation on the wall face – ideal where ceiling mounting is not possible or desired.

Made from stainless steel (AISI 304L) with heavy duty polymer rollers and an anti-jump device, the Runway front-mounted barn door hardware is available in satin stainless steel and black powder coated finish. Height adjustable wall mounts of ±1/8" ensure precise installation. Soft close is optionally available. Supports wooden door weights of up to 176 lbs (80 kg) with a door thickness of 1-7/16" to 1-3/4".

Available for single and biparting door configurations in three passage widths from 29-1/2" to 49-3/16". ANSI/BHMA A156.14-2013 Grade 1 internal test certified.

1 3

Surface Satin stainless steel Steel black powdered

Passage width 29-1/2" - 35-7/16" (750-900mm) 35-13/16" - 39-3/8" (910-1000mm) 44-1/2" - 49-3/16" (1130-1250mm)

Number of door leaves 1

SKU:

SKU:110.00543

$1,063.00 USD

Sale Sold out

Shipping calculated at checkout.

View full details

Product Information

Features
Single and biparting door sets
Anti-jump device
Made from stainless steel (AISI304L)
Heavy duty polymer roller
Finish options: satin stainless steel, aluminum black powdered
Benefits
Match ANSI/BHMA A156.14-2013 Grade 1 internal test
Door thickness: 1 7/16” – 1 3/4”
Initial friction < 10 NM Maximum
Door weight: 176 lbs (80 kg)
Height adjustable wall mounts ± 1/8”
Scope of Delivery
Single door:
1 track rail
2 trolleys
3 (4) wall mounts
2 door stoppers
1 door bottom guide
1 Allen key (SW5)
Installation screws

Biparting door:
2 track rails + connector
4 trolleys
6 (8) wall mounts
4 door stoppers
2 door bottom guides
1 Allen key (SW5)
Installation screws

Technical Details

The Runway barn door hardware for wooden doors, front-mounted, features a modern and clean design with concealed rollers that make the carriage appear to glide invisibly along the track. Unlike ceiling-mounted systems, the front-mounted version allows direct installation on the wall face – ideal where ceiling mounting is not possible or desired.

Made from stainless steel (AISI 304L) with heavy duty polymer rollers and an anti-jump device, the Runway front-mounted barn door hardware is available in satin stainless steel and black powder coated finish. Height adjustable wall mounts of ±1/8" ensure precise installation. Soft close is optionally available. Supports wooden door weights of up to 176 lbs (80 kg) with a door thickness of 1-7/16" to 1-3/4".

Available for single and biparting door configurations in three passage widths from 29-1/2" to 49-3/16". ANSI/BHMA A156.14-2013 Grade 1 internal test certified.
